– Folding Door Mechanism for IKS
Plus
An integrated system for IKS folding doors. An aluminum profile mounts to the top of the wardrobe and houses a sliding carriage with a rotating arm. Doors screw to the arm and fold to a 160° opening, paired with IKS 180° hinges and an aluminum folding hinge placed between the two doors.
Carriage-and-Arm Folding Mechanism
The Plus mechanism integrates with the IKS hinged door system to create folding wardrobe doors. An aluminum profile mounts to the top of the wardrobe and houses a sliding carriage equipped with a rotating arm. Door movement is controlled by two CAMs – one CAM controls the opening sequence, the other controls the closing sequence – with built-in smoves to dampen each motion.
The system pairs with the IKS 180° hinge (IS-CE-180) at the cabinet edge and an aluminum folding hinge placed between the two doors. The carriage trolley uses 15 wheels for smooth lateral travel, and a tension spring can be set to one of three positions (high, medium, or low) to match the weight of the doors. The configuration produces a 160° opening, with a 32mm clearance between the wardrobe and the open door – enough to access drawers inside.
Available Finishes
Trolley standard finish: Painted Black. Anodised profiles: 12–14 micron (black), 10–12 micron (other colours).
Need a Quote?
Share your wardrobe top dimensions, opening direction (left or right), and door configuration. Our team will provide pricing tailored to your Plus specification.
SPECIFICATIONS
– Key Features
What the Plus System Delivers
01
160° Folding Opening
The carriage and arm fold the doors to a 160° opening, providing wide-open access to the wardrobe interior.
02
Two-CAM Motion Control
A hinge-side CAM controls opening with a smove and non-return system; a stop-side CAM controls closing with two smoves for damped travel.
03
Adjustable Spring Tension
The internal spring sits in three positions – high, medium, or low traction – and can be tuned on-site to match the door weight.
04
15-Wheel Sliding Carriage
The trolley uses 15 wheels for smooth lateral travel, with a rotating arm that drives the door fold throughout the motion.
05
Drawer-Compatible Clearance
A 32mm gap between the wardrobe and the open door allows drawers inside the wardrobe to be opened with the doors fully folded.
06
Left or Right Configuration
Specify left-opening (PS-MECCANISMO-SX-VNO) or right-opening (PS-MECCANISMO-DX-VNO) to suit cabinet layout.
– System Compatibility
Works With These Products
Plus is engineered as an extension of the IKS family. It pairs directly with the IKS 180° hinge and IKS door frames, and integrates with the AluminumXDesign wardrobe range.
IKS Door System
IKS
Required base hinge system – uses IKS 180° (IS-CE-180)
IS-954 Door Frame
IKS aluminum door profile for glued glass
Wardrobe Structures
Only
Aluminum wardrobe profile system with hidden joints
Easy Only
Simplified aluminum wardrobe structure
Related Hinged Door Systems
Mini IKS
Compact concealed hinge system for smaller doors
Deseo
Side-mounted hinge glass door system
