– Glass Wall System for Interior Spaces
Stealth
A glass wall system for dividing interior spaces. Stealth combines fixed and sliding glass doors in 8mm, 10mm, or 12mm thickness, mounted on a slim aluminum rail with carriage, clamps, and adjustment profiles. The system is engineered for fast on-site installation and is also available as a recessed Hidden Stealth configuration for plasterboard installation.
Glass Wall System for Interior Spaces
Stealth is engineered for dividing interior spaces with full-height glass. The system pairs fixed glass panels with sliding glass doors mounted on a slim aluminum rail, with carriage, covering carter, adjustment profiles, and clamps acting as the structural elements. The result is a glass partition that delivers transparency and brightness while remaining straightforward to install on site.
Stealth supports glass thickness of 8mm, 10mm, or 12mm. Each carriage and clamp provides vertical adjustment of +5/-8mm for on-site alignment. The system is supplied in three configurations – fixed + sliding, wall-mounted, and 2-way – plus a recessed Hidden Stealth variant for clean integration into plasterboard ceilings.
Available Finishes
Anodised: 12–14 micron (black), 10–12 micron (other colours)
Need a Quote?
Share your opening dimensions, glass thickness, configuration (fixed+sliding, wall-mounted, 2-way, or Hidden), and finish. Our team will provide pricing tailored to your Stealth specification.
SPECIFICATIONS
– System Compatibility
Works With These Products
Stealth is designed for whole-room interior applications. It pairs with the AluminumXDesign wardrobe, structure, and shelving range to create complete walk-in environments.
Related Sliding Door Systems
Wardrobe Structures
Only
Aluminum wardrobe profile system with hidden joints
Easy Only
Simplified aluminum wardrobe structure
Modular Structures
Shelving & Wardrobe Accessories
– Key Features
What Stealth Delivers
01
8 / 10 / 12mm Glass
Specify glass thickness of 8mm, 10mm, or 12mm. Each clamp ships with the matching gasket set to suit the chosen glass.
02
Vertical Adjustment
Each carriage and clamp delivers +5/-8mm of vertical adjustment, allowing precise alignment of the glass against the floor profile after installation.
03
Optional Soft-Close
The RS-940 soft-closing mechanism can be specified to dampen and decelerate the sliding door at the end of its travel.
04
Recessed Hidden Variant
Hidden Stealth integrates the entire rail and carriage assembly into a plasterboard ceiling cavity for a fully concealed architectural finish.
05
Architectural Glass Wall
Designed for dividing interior spaces – walk-in wardrobes, glazed offices, and architectural partitions where transparency is required.
06
Italian Design, USA Made
Rooted in Italian craftsmanship tradition, manufactured at our Chatsworth, California facility for North American specification.
– Configuration Options
Four System Configurations
Stealth is supplied in four configurations to suit different architectural conditions, from open spaces with fixed glass partitions to fully recessed installations in plasterboard ceilings.
01
Fixed + Sliding
Combines a fixed glass panel with one or more sliding glass doors on a single rail. The system uses dedicated closing profiles for each glass type (fixed, sliding, or both) to maintain a clean architectural line.
Key Components
02
Wall-Mounted
A simplified single-rail configuration where the sliding glass door is mounted to a wall, with no fixed glass panel required. Ideal for partitioning a doorway in an existing wall opening.
Key Components
03
2-Way
A dual-track configuration where two sliding glass doors run on separate tracks within a single rail, allowing both doors to slide past each other independently.
Key Components
04
Hidden Stealth
A fully recessed installation with the rail concealed inside a plasterboard ceiling. Available in 1-way, fixed+sliding, and 2-way variants, supported by a dedicated cross-bar, side profile, and closing cap system.
Key Components
– Get Started
Configure Your Stealth Glass Wall
Tell us about your project and we will help you select the right configuration, glass thickness, and finish for the architectural condition.
